• Technical parameters
• cast-iron machine bed –(spindle headstock) – and frame structure,
• cast-iron beam and vertical slide system,
• side head with mechanical counterweight,
• breast-beam fixation, mechanical design,
• beams (Z1, Z2) fitted with hydraulic counterweight
• hydrostatic table design,
• main spindle with cylindrical roller bearing support with conical bore,
• transfer box gearing with the original one retained, with 4 speeds (16)
• castiron-castiron slide system conversion, creating a cast-iron-ZX100 sliding surface,
• backlash-free ballscrew-ballnut actuation for  X1, X2 slide movement on beam, - backlash-free ballscrew-ballnut actuation in beam Z1, Z2,
• creating a 5-position automatic turret
• connecting of feed drive motors to ballscrews by via couplings,
• measuring system – rotary encoder integrated into motor on all axes,
• partial work space cover with lighting,
• with step grill toward working space for the operator,
• covering of main assemblies and actuating elements with enveloping elements, (unpainted, rubbed up)
• chain-type chip conveyor with chute plates in working space,
• designing of coolant system, coolant supply system,
• manual wash-down (flush-out) of working space, supply of 2,5 bar, 40l/min,
• electric box,
• separate/remote slewing control panel,
• NCT 201 control system, so-called two-path design for actuating X1-Z1, X2-Z2, slides,
• side head control independent from the other two slides,
• adaptation to NCT drives and controls by utilizing the main motor (40kW),
• operating network 380V, 50Hz, 3ph





•
•
•
