• Cast-iron bed grouted with concrete mortar
• 60°-inclined cross slide
• Ground, assembled slideways hardened in their full cross-section
• Cast-iron headstock , reinforced main spindle
• MC execution
• Automatic door movement
• 12-position turret with bidirectional positioning
• Thread-cuting rotary encoder
• Measuring system w.th rotary encoder built in the motor
• Hydrailic unit for chuck and tailstock
• Hydraulic tailst. quill movement via foot switch
• Programmable tailstock centre,
• Tailstock body fixation by hydraulics, movement by dragging
• Foot switch for chuck actuation
• Two-stage bach gear
• Chip conveyor equipment, compl.
• Coolant supply system, compl.
• Manual washing of working area
• Working area cover, compl.
• Machine lamp
• Electric box with heat exchanger built in cover
• FANUC 31i CNC control unit, with  Manual Guide Service that supports programming.

Option

• FANUC kW 37/45 drive and main motor
• FANUC electronic handwheel
• FANUC AC feed drive and motors
• 380V, 50Hz, 3ph. actuating network
